MAIN FEATURES
SAILOMAT 700-SERIES

All-mechanical servo-pendulum principle

• superior sensitivity and yaw damping
• state-of-the-art design (SAILOMAT patents)

Superior steering performance

• also in light winds
• variable vane-to-oar ratio

Advanced all-aluminum design

• very high tensile strength, marine grade
• lightweight
• anodized, no welded parts, no painting

Custom designed to fit all types of sailboats

• 24-50 feet LOA
• tiller or wheel-steered

Compact universal mounting base

• four bolts to hull, all transom slope angles
• also double ender

Off-center mounting possible

• ideal for modern walk-thru geometries
• clearing a swim ladder

Simple removal from mounting base

• for stowing

Wide blade side-swing ability

• out of water (148° to side)
• overload safety
• blade parking

Slanted servo blade, 34° from vertical

• ideal for modern transom geometries
• pumping off disturbing sea weed, automatic

Line circuit to wheel or tiller

• vertical lines from compact 'winglets' lever arms
• avoiding transom 'line clutter'
• simpler block positioning
• low-friction standard blocks
